Overview

2027 Polaris Ranger 1000 CAB

Side by Side (SxS)

Ranger 1000 CAB

Stay warm in cool weather, the RANGER 1000 CAB combines protection from the elements with factory-installed heat and an enclosed cab, so you can get the job done no matter the conditions.

Starting at $21,999 MSRP
Manufacturer suggested retail price. Does not include dealer fees, tax, title, or registration.

Specs & Features

ENGINE & DRIVETRAIN
Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/VersaTrac Turf Mode
Driveline Features
N/A
Engine Type
4-stroke twin cylinder SOHC
Fuel System
Electronic fuel injection
Horsepower
61
Transmission/Final Drive
Gen 2 Automatic PVT H/L/N/R/P; shaft
DIMENSIONS
Bed Box Dimensions
36.75 x 54.25 x 12.5" (93 x 138 x 32 cm)
Box Capacity
1,000 lbs. (454 kg) CA Models: 600 lbs. (272 kg)
Estimated Dry Weight
1,720 lbs. (780 kg)
Accessory Weight
N/A
Fuel Capacity
11.35 gal (43 L)
Ground Clearance
12.5" (31.75 cm)
Towing Capacity
2,500 lbs. (1134 kg)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
120 x 65 x 78" (305 x 165x 193 cm)
Payload Capacity
1,500 lbs. (680 kg) CA Models: 1,100 lbs. (499 kg)
Person Capacity
3
Turning Radius
13.3' (4 m)
Wheelbase
81" (206 cm)
SUSPENSION
Front Suspension
Dual A-arm, 10" (25.4 cm) travel
Rear Suspension
Dual A-arm, 10" (25.4 cm) travel
TIRES / WHEELS
Front Tires
26 x 9-12; PXT 2.0
Rear Tires
26 x 11-12; PXT 2.0
Tire Ply Rating
6-ply
Wheels
12" aluminum
Brakes
Front/Rear Brakes
4-wheel hydraulic disc with dual-bore front and rear calipers
Parking Brake
Park in-transmission
Technology
Audio System
Not equipped, accessory options available
Connected Vehicle Services
Not equipped, accessory options available
Touch Screen Display
Not equipped, accessory options available
Rear Camera
Not equipped, accessory options available
Security
N/A
COMFORT & CONVENIENCE
Driver Instrumentation
4" LCD rider information center: user selectable blue/red backlighting and brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
Seat Type
3-person bench seat with 3-point harness and adjustable driver seat
Steering
Tilt adjustment
Electronic Power Steering
High-output EPS
Cab Components
Factory-installed cab system with roof and sound insulation materials, fixed glass windshield, tinted rear panel, crank front windows, windshield wiper/washer, dome light
Heat and/or Air Conditioning
Factory-installed heat and defrost
Speed Limiting
Not equipped, accessory options available
LIGHTING & ELECTRICAL
Lighting
Dual LED headlights, 600-lm low beam, 1,000-lm high beam, dual LED taillights
Electrical System
660-W charging system, Polaris Pulse electrical system (3-position), 12V accessory outlet, battery trickle-charging port
EXTERIOR FEATURES
Winch
4,500 LB Winch with synthetic rope, Auto Stop and wireless remote
Vehicle Protection
Large steel bumper, full-coverage skid plate, CV Shields
Door Type
Crank window doors
Cargo System
Gas-assist dump box with Lock & Ride accessory integration
ADDITIONAL SPECIFICATIONS
Warranty
1-year limited warranty*
STAY COMFORTABLE IN THE COLD
Weatherproof your plans with an enclosed cab and experience year-round use of your vehicle in comfort with factory-installed heat.
EXTRA PULLING POWER
Complete the job or get back on the trail quicker, thanks to the pulling power of a factory-installed 4,500 LB Winch with synethic rope, Auto Stop and wireless remote, available on RANGER 1000 Premium and CAB.
HEAVIER LOADS, FEWER TRIPS
Class-leading 1,000-lb. box capacity and 2,500-lb. towing capacity to get more done in fewer trips.
EFFORTLESS SHIFTING
Gen 2 transmission reduces shift effort by up to 50%, so you can move between drive, park and reverse with less effort and more control.
