Overview

2027 Polaris Ranger 500

Side by Side (SxS)

Ranger 500

With work-ready features like a dump box, factory-installed winch and more, RANGER 500 is the smart choice for those looking to take on to-dos without breaking the bank.

Starting at $9,999 MSRP
Manufacturer suggested retail price. Does not include dealer fees, tax, title, or registration.

Specs & Features

ENGINE & DRIVETRAIN
Cooling
Liquid
Cylinders Displacement
567 cc
Drive System Type
All-wheel drive with auto-locking front drive and selectable VersaTrac Turf Mode
Driveline Features
N/A
Engine Type
4-stroke single cylinder DOHC
Fuel System
Electronic fuel injection
Horsepower
28
Transmission/Final Drive
Automatic PVT H/L/N/R/P; shaft
DIMENSIONS
Bed Box Dimensions
32.6 x 46.2 x 11.25" (82.8 x 117.3 x 28.6 cm)
Box Capacity
500 lbs. (227 kg)
Estimated Dry Weight
1,155 lbs. (524 kgs)
Accessory Weight
N/A
Fuel Capacity
9.5 gal (36 L)
Ground Clearance
10" (25.4 cm)
Towing Capacity
1,500 lbs. (680 kg)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
110 x 58.5 x 74.8" (279 x 149 x 190 cm)
Payload Capacity
1,000 lbs. (454 kg)
Person Capacity
2
Turning Radius
13.5' (4.2 m)
Wheelbase
73" (186 cm)
SUSPENSION
Front Suspension
MacPherson strut 9" (22.9 cm) travel
Rear Suspension
Dual A-arm, IRS 10" (25.4 cm) travel
TIRES / WHEELS
Front Tires
25 x 8-12; Carlstar 489
Rear Tires
25 x 10-12; Carlstar 489
Tire Ply Rating
----
Wheels
4-wheel hydraulic disc
Brakes
Front/Rear Brakes
Park in-transmission
Parking Brake
Not equipped, accessory options available
Technology
Connected Vehicle Services
N/A
Touch Screen Display
N/A
Rear Camera
N/A
Security
Yes
COMFORT & CONVENIENCE
Driver Instrumentation
4" LCD rider information center: user-selectable blue/red backlighting and brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
Seat Type
2-person, flip-up bench seat with 3-point harness
Steering
Tilt adjustment
Electronic Power Steering
N/A
Cab Components
Roof
Heat and/or Air Conditioning
N/A
Speed Limiting
Speed limiting controlled in gauge
LIGHTING & ELECTRICAL
Lighting
LED headlights & taillights
Electrical System
DC outlet, 660-W stator charging system
EXTERIOR FEATURES
Winch
2,500 LB Winch with wired remote
Vehicle Protection
Steel front bumper with integrated winch mount
Door Type
Cab nets
Cargo System
Gas-assist dump box with Lock & Ride accessory integration
ADDITIONAL SPECIFICATIONS
Warranty
1-year limited warranty*
CONVENIENTLY SIZED
Easily store and navigate small spaces with a narrow 58.5” width.
OUTWORKS A WHEELBARROW
Make fewer trips with the gas-assist dump box. It can haul up to 500 lbs.—approximately 15 bags of dry mulch.
INSTANT TRACTION
AWD with auto-locking front drive automatically engages when it senses tire slip, giving you added traction across changing terrain without additional input.
