Overview

2027 Polaris Ranger Crew XD 1500 NorthStar Mountaineer Edition

Side by Side (SxS)

Ranger Crew XD 1500 NorthStar Mountaineer Edition

Mountaineer Edition delivers 20% more low-end torque than standard RANGER XD 1500 for smooth uphill climbs and heavy-duty performance at high elevation.

Starting at $50,499 MSRP
Manufacturer suggested retail price. Does not include dealer fees, tax, title, or registration.

Specs & Features

ENGINE & DRIVETRAIN
Cooling
Liquid
Cylinders Displacement
1498 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/Turf/Ultra Turf, Drive modes: Comfort, Standard, Sport, Tow/Haul
Driveline Features
Drive mode-specific engine braking, hill assist, and creep in drive and reverse
Engine Type
4-stroke triple cylinder DOHC
Fuel System
Electronic fuel injection
Horsepower
110
Transmission/Final Drive
STEELDRIVE automatic transmission: D/R/P
DIMENSIONS
Bed Box Dimensions
43.4 x 56 x 13.4" (110.2 x 142.2 x 34 cm)
Box Capacity
1,500 lbs. (680 kg)
Estimated Dry Weight
3,282 lbs. (1488 kg)
Accessory Weight
N/A
Fuel Capacity
13.6 gal (51.5 L)
Ground Clearance
15" (38 cm)
Towing Capacity
3,500 lbs. (1588 kg)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
164 x 65 x 78" (416.5 x 165 x 198 cm)
Payload Capacity
1,650 lbs. (748 kg)
Person Capacity
6
Turning Radius
19.4' (6 m)
Wheelbase
127" (322.6 cm)
SUSPENSION
Front Suspension
Dual arched A-arm 12" (30.5 cm) travel
Rear Suspension
Dual arched A-arm, IRS 12" (30.5 cm) travel
TIRES / WHEELS
Front Tires
30 x 10-15; KENDA® CROSS TRAIL
Rear Tires
30 x 11-15; KENDA® CROSS TRAIL
Tire Ply Rating
8-ply
Wheels
15" aluminum
Brakes
Front/Rear Brakes
Foot-activated and power-assisted, 4-wheel hydraulic disc with dual-bore front and rear calipers
Parking Brake
Park in-transmission
Technology
Audio System
JBL Trail Pro 2000 audio
Connected Vehicle Services
RIDE COMMAND+ connected vehicle services including real‑time vehicle location, vehicle security alerts, remote ignition lockout, vehicle health diagnostics, and maintenance reminders. Free three-year subscription of RIDE COMMAND+ included with purchase of vehicle when factory installed.
Touch Screen Display
7" Display powered by RIDE COMMAND, featuring built‑in GPS navigation with topographic mapping, Group Ride (cell‑based or GPS‑based) with messaging, ride tracking, configurable gauges, waypoints, help alerts, Bluetooth® audio, AM/FM radio, and USB smartphone connectivity. Includes Plow-Mode when properly equipped.
Rear Camera
Factory rear camera
Security
Polaris P.A.S.S. anti-theft system
COMFORT & CONVENIENCE
Driver Instrumentation
Driver forward information center with 4" color display and analog speedometer and tachometers: user-selectable blue/red backlighting and brightness, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, oil pressure, transmission indicator, EPS indicator, voltmeter, service indicator and codes, seat belt reminder
Seat Type
6-person, dual-row, superior contoured, bolstered bench seats with 3-point harness, heated front row seats, adjustable driver seat, and flip-down arm rest
Steering
Tilt & telescoping adjustment
Electronic Power Steering
High-output EPS
Cab Components
Factory-installed cab system with sound insulation materials, tip-out glass windshield, tinted side windows and rear panel, powered front and rear windows, rearview mirror, windshield wiper/washer
Heat and/or Air Conditioning
Factory-installed heat, AC, defrost, recirculation with 5 different airflow settings
Speed Limiting
Speed limiting controlled in RIDE COMMAND
LIGHTING & ELECTRICAL
Lighting
LED headlights with LED taillights, rear LED light, LED dome light, door puddle lighting, front LED auxiliary lights, interior accent lighting, lighting modes: low, high, accent, blackout. Blackout mode switches off the headlights and dims interior lighting
Electrical System
140-amp charging system, Polaris PULSE electrical system (3-position hood and 3-position roof), USB charger, trickle charger, 12-volt accessory outlet, battery trickle-charging port
EXTERIOR FEATURES
Winch
Pro Series 6,000 LB Winch with synthetic rope, Auto Stop, and wireless remote
Vehicle Protection
Large steel bumper, full-coverage skid plate, bumper D-rings, and top bar
Door Type
Powered front and rear window doors
Cargo System
Electronic lift dump box with Lock & Ride MAX accessory integration
ADDITIONAL SPECIFICATIONS
Warranty
1-year limited warranty*
CLIMB CONFIDENTLY
Designed with a lower gear ratio that delivers more low-end torque and limits top speed for smooth uphill climbs and steady handling in rocky, high-altitude terrain where every move counts.
WEATHERPROOF YOUR PLANS
Enjoy advanced comfort and convenience with a fully enclosed cab system—complete with a heating and air conditioning system offering 5 different air flow settings.
INDUSTRY-LEADING TECHNOLOGY
Elevate your off-road experience with nationwide off-road navigation via the 7"" Display powered by RIDE COMMAND and premium sound thanks to integrated JBL® audio on RANGER XD 1500 NorthStar Ultimate.
POWER YOUR PRODUCTIVITY
RANGER XD 1500 NorthStar is powered by a 3-cylinder ProStar 1500cc engine. It pumps out 110 HP and 105 lb.-ft. of torque for effortless hauling and towing and confidence on tough terrain.
MAXIMUM DURABILITY & STRENGTH
The industry-exclusive STEELDRIVE transmission features a 100% steel-constructed belt. It’s designed to withstand heavier loads and require less maintenance than the rubber belt design commonly found in other UTVs. Plus, it’s fully sealed and liquid-cooled for maximum durability and longevity.
