2027 Polaris Ranger Crew XD 1500 NorthStar Premium

Side by Side (SxS)

Ranger Crew XD 1500 NorthStar Premium

Part of our Extreme Duty class. The strongest, most capable and comfortable RANGER with all-season comfort and elevated in-cab features.

Starting at $45,499 MSRP
Manufacturer suggested retail price. Does not include dealer fees, tax, title, or registration.

Specs & Features

ENGINE & DRIVETRAIN
Cooling
Liquid
Cylinders Displacement
1498 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/Turf/Ultra Turf, Drive modes: Comfort, Standard, Sport, Tow/Haul
Driveline Features
Drive mode-specific engine braking, hill assist, and creep in drive and reverse
Engine Type
4-stroke triple cylinder DOHC
Fuel System
Electronic fuel injection
Horsepower
110
Transmission/Final Drive
STEELDRIVE automatic transmission: D/R/P
DIMENSIONS
Bed Box Dimensions
43.4 x 56 x 13.4" (110.2 x 142.2 x 34 cm)
Box Capacity
1,500 lbs. (680 kg)
Estimated Dry Weight
3,244 lbs. (1471 kg)
Accessory Weight
N/A
Fuel Capacity
13.6 gal (51.5 L)
Ground Clearance
15" (38 cm)
Towing Capacity
3,500 lbs. (1588 kg)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
164 x 65 x 78" (416.5 x 165 x 198 cm)
Payload Capacity
1,690 lbs. (766 kg)
Person Capacity
6
Turning Radius
19.4' ( 6 m)
Wheelbase
127" (322.6 cm)
SUSPENSION
Front Suspension
Dual arched A-arm 12" (30.5 cm) travel
Rear Suspension
Dual arched A-arm, IRS 12" (30.5 cm) travel
TIRES / WHEELS
Front Tires
30 x 10-15; KENDA® CROSS TRAIL
Rear Tires
30 x 11-15; KENDA® CROSS TRAIL
Tire Ply Rating
8-ply
Wheels
15" aluminum
Brakes
Front/Rear Brakes
Foot-activated and power-assisted, 4-wheel hydraulic disc with dual-bore front and rear calipers
Parking Brake
Park in-transmission
Technology
Audio System
Not equipped, accessory options available
Connected Vehicle Services
Not equipped, accessory options available
Touch Screen Display
Not equipped, accessory options available
Rear Camera
Not equipped, accessory options available
Security
Polaris P.A.S.S. anti-theft system
COMFORT & CONVENIENCE
Driver Instrumentation
Driver forward information center with 4" color display and analog speedometer and tachometers: user-selectable blue/red backlighting and brightness, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, oil pressure, transmission indicator, EPS indicator, voltmeter, service indicator and codes, seat belt reminder
Seat Type
6-person, dual-row, superior contoured and bolstered bench seats with 3-point harness, adjustable driver seat, and flip-down arm rest
Steering
Tilt & telescoping adjustment
Electronic Power Steering
High-output EPS
Cab Components
Factory-installed cab system with sound insulation materials, fixed glass windshield, tinted side windows and rear panel, powered front and rear windows, rearview mirror, windshield wiper/washer
Heat and/or Air Conditioning
Factory-installed heat, AC, defrost, recirculation with 5 different airflow settings
Speed Limiting
Speed limiting controlled in gauge
LIGHTING & ELECTRICAL
Lighting
LED headlights with LED taillights, LED dome light, door puddle lighting, interior accent lighting, lighting modes: low, high, accent, blackout. Blackout mode switches off the headlights and dims interior lighting
Electrical System
140-amp charging system, Polaris PULSE electrical system (3-position hood and 3-position roof), USB charger, trickle charger, 12-volt accessory outlet, battery trickle-charging port
EXTERIOR FEATURES
Winch
Pro Series 6,000 LB Winch with synthetic rope, Auto Stop, and wireless remote
Vehicle Protection
Large steel bumper, full-coverage skid plate
Door Type
Powered front and rear window doors
Cargo System
Electronic lift dump box with Lock & Ride MAX accessory integration
Cargo System
Warranty
2-year limited warranty*
WEATHERPROOF YOUR PLANS
Enjoy advanced comfort and convenience with a fully enclosed cab system—complete with a heating and air conditioning system offering 5 different air flow settings.
POWER YOUR PRODUCTIVITY
RANGER XD 1500 NorthStar is powered by a 3-cylinder ProStar 1500cc engine. It pumps out 110 HP and 105 lb.-ft. of torque for effortless hauling and towing and confidence on tough terrain.
MAXIMUM DURABILITY & STRENGTH
The industry-exclusive STEELDRIVE transmission features a 100% steel-constructed belt. It’s designed to withstand heavier loads and require less maintenance than the rubber belt design commonly found in other UTVs. Plus, it’s fully sealed and liquid-cooled for maximum durability and longevity.
